SKU:FE700GA27
Brand:Fluke
Availbility:
In stock
Fluke Digital Pressure Gauge - Calibrator Pressure Gauge (0 to 300 psi) With Calibration Certificate - FE700GA27
$1,900.00
Free Shipping Over $75
Satisfaction Guaranteed
Secure Checkout
Enhance Your Gear With Accessories
Fluke Digital Pressure Gauge - Calibrator Pressure Gauge (0 to 300 psi) With Calibration Certificate - FE700GA27
$1,900.00
Also known as lab test gauges, these Grade 5A digital gauges measure pressure in high-precision laboratory applications where 0.05% accuracy is required. These gauges allow users to toggle between units of measure.
- Brand
- FLUKE
- Accuracy
- ±0.05%
- Gauge Case Material
- Cast Zinc Aluminum
- Nominal Dial Size
- 3-3/4 in
- Process Connection Gender
- Male
- Process Connection Size
- 1/4 in
- Process Connection Type
- NPT
- Accuracy Grade
- Not Graded
- Pressure Gauge Type
- Test Pressure Gauge
- Pressure Range Type
- Pressure
- Vibration Resistance
- Explosion Proof
- Includes Calibration Certificate
- NIST with Data
- Includes
- Manual on CD; NPT/Metric Adapter; Protective Cover
- Manufacturer Part Number
- FLUKE-700GA27
- Series
- 700G
- Adjustable Set Points
- No
- Auto-Shutoff
- Yes
- Backlit Screen
- Yes
- Battery Run Time
- 1,500 hr
- Blowout Safety Back
- No
- Burst Pressure
- 1,200 psi
- Case Color
- Yellow
- Case Diameter
- 3.75 in
- Display Range
- 0 to 20 bar; 0 to 300 psi
- Display Screen Type
- LCD
- Hazardous Location Rating
- Class I, Div 2, Group A, D
- Includes Batteries
- No Batteries Included
- Includes Mounting Hardware
- No
- Includes Rubber Boot
- No
- Languages
- English
- Manufacturer Warranty Length
- 3 yr
- Mounting Type
- Stem-Mount
- Non-Sparking
- No
- Number of Digits
- 5
- Panel-Mountable
- No
- Peak Hold
- No
- Power Source
- Battery
- Sensor Material
- Silicon Substrate
- Socket Material
- Stainless Steel
- Standards
- ATEX; CSA
- Case Material
- Aluminum
- Connection Location
- Bottom
- Gauge Wetted Parts
- Stainless Steel
- Pressure Range (non-Primary)
- 0 psi to 300 psi
- Process Connection
- 1/4 in NPT Male
- Process Connection Location
- Bottom
- Test Pressure Gauge Type
- Calibrator Pressure Gauge
- Certificate of Calibration
- Included
- Differentiator (HIDDEN)
- FLUKE-700GA27 NIST with Data
- Compatible with Series
- Fluke 700 Series
- Compatible with Manufacturer Part Number
- 700HTPK; 700PTPK
- IP Rating
- IP67
- NEMA Enclosure Rating
- No Enclosure
- Operating Temperature - Minimum
- 14 °F
- Pressure Measurement - Maximum
- 300 psi
- Pressure Measurement - Minimum
- 0 psi
- Process Media Temperature - Maximum
- 131 °F
- Process Media Temperature - Minimum
- -14 °F
- Vacuum Measurement - Maximum
- 1,200 psi
- Vacuum Measurement - Minimum
- 0 psi
- Series
- 700G
- Wetted Parts Material
- Stainless Steel Silicon Substrate
- Primary Pressure Range
- 0 psi to 300 psi
- UNSPSC
- 41112403
- Country of Origin
- China (subject to change)
